Handcrafted Trumpet Mouthpieces
For more than 65 years, Schilke Music Products has been a leader in trumpet mouthpiece design and manufacturing in the world. We offer a large array of choices for the brass instrument family. Schilke also offers a full custom design division to create that one-of-a-kind special mouthpiece.
Standard Series Trumpet Mouthpieces
These mouthpieces were a collaboration with trumpet artists and colleagues of Renold Schilke from 1950’s and early 1960’s.
| Model | mm | Inches | Throat | Description |
|---|---|---|---|---|
| 5A4a | 15.84 | 0.624 | 27 | Small cup diameter with tighter "A" backbore and semi-flat rim offers comfort and resistance in the upper register. |
| 5A4 | 15.84 | 0.624 | 26 | Same as the 5A4a but with a standard "c" backbore and larger throat, which offers less resistance. |
| 6A4a | 15.99 | 0.63 | 27 | A shallow "A" cup with cushion #4 rim for extreme high register work. |
| 7B4 | 16.08 | 0.633 | 26 | Excellent for the player with thin lips. A #4 rim provides good endurance with a brilliant tone. |
| 8A4 | 16.25 | 0.64 | 26 | The slightly funnel-shaped cup at the entrance to the throat provides a good tone and the #4 semi-flat rim gives superior endurance. |
| 8E2 | 16.15 | 0.636 | 26 | The deep funnel-shaped cup provides a smooth tone and is very flexible in all registers. Recommended for cornet players. |
| 9 | 16.33 | 0.643 | 26 | Standard characteristics allow for a full penetrating tone quality. |
| 9C4 | 16.36 | 0.644 | 26 | Like the #9, however the #4 semi-flat rim provides excellent endurance. |
| 10A4a | 16.43 | 0.647 | 27 | The combination of the shallow "A" cup, semi-flat #4 rim and tight "a" backbore assists with upper register work. |
| 10A4 | 16.43 | 0.647 | 27 | Same as the 10A4a but with a standard "c" backbore, which offers less resistance. |
| 10B4 | 16.43 | 0.647 | 26 | A medium-small funnel-shaped "B" cup offers both a quality sound and support in the register |
| 11A | 16.51 | 0.65 | 26 | This rim size and contour is similar to the #11 but with a shallower "A" cup. |
| 11AX | 16.51 | 0.65 | 27 | This model was developed for the Schilke piccolo trumpets. The "x" backbore improves the ease of playing and opens up the sound on the piccolo. Also available in a trumpet shank. |
| 11C2 | 16.51 | 0.65 | 26 | Similar to the #11 featuring a slightly rounded #2 rim countour. |
| 11 | 16.53 | 0.653 | 26 | A superior mouthpiece with standard characteristics for a free blowing mouthpiece. |
| 11D4 | 16.58 | 0.653 | 26 | Slightly deeper than the #11 with a #4 semi-flat rim, which provides a definate cushion feel for endurance. |
| 11E | 16.58 | 0.653 | 26 | The large funnel-shaped cup encourages a big round tone, ideal for cornet. |
| 12A4a | 16.71 | 0.658 | 27 | Similar to the 12B4 but with a shallow "A" cup, tight "a" backbore which adds both endurance and range. |
| 12A4 | 16.71 | 0.658 | 27 | This mouthpiece is the same as a 12A4a but with a standard "c" backbore. |
| 12B4 | 16.71 | 0.658 | 26 | This medium-small conical "B" cup provides a full tone and the #4 semi-flat rim allows for more endurance. |
| 12 | 16.69 | 0.657 | 26 | A traditional medium size mouthpiece that includes a #3 standard rim and "c" backbore allows the player a full spectrum of sound. |
| 13A4a | 16.76 | 0.66 | 27 | The shallow ?A? cup, semi-flat #4 rim and tight "a" backbore creates an ideal lead mouthpiece. |
| 13A4 | 16.76 | 0.66 | 27 | Same as the 13A4a but with the standard "c" backbore which allows a freer blowing feel. |
| 13B | 16.77 | 0.66 | 26 | This mouthpiece has a "B" cup that is slightly deeper than the 13A4 and also offers a narrower, round rim. |
| 13 | 16.89 | 0.665 | 26 | Ideal choice for a student or developing player with standard #3 rim contour. Rounder rim provides increased flexibility and quick response. "C" cup offers volume for tone. |
| 13C4 | 16.89 | 0.665 | 26 | A somewhat sharp inner-edge combined with a funnel-shaped "C" cup offers a clear tone. The #4 semi-flat rim adds increased endurance. |
| 13D4 | 16.89 | 0.665 | 27 | Best option for a player looking for a thick, rich, weighted sound. Medium large "D" cup offers a tone that is colorful with depth. #4 semi-flat rim affords comfort with sharper bite for superior articulation clarity. Diameter ideal for all players from student to professional. |
| 14A4a | 17.09 | 0.673 | 27 | One of our most popular mouthpieces, the 14A4a offers a shallow "A" cup, semi-flat #4 rim and tight "a" backbore allows a player a strong upper register without sacrificing tonal production. |
| 14A4 | 17.09 | 0.673 | 27 | Same as the 14A4a but with a standard "c" backbore which offers a more "open" feel. |
| 14A4x | 17.09 | 0.673 | 27 | Based on the popular 14A4a, this mouthpiece creates a very open blowing feel with the large ?x? backbore. This backbore improves the ease of playing and opens up the sound of our piccolo trumpet. Also ideal for Eb soprano cornet. |
| 14B | 17.02 | 0.67 | 26 | Similar to the #14 but with a "B" (medium-small) cup size. |
| 14C2 | 17.02 | 0.67 | 26 | This "C" cup and #2 semi-rounded rim produces a rather large tone and good center. |
| 14 | 17.02 | 0.67 | 26 | With a standard rim, cup and backbore, the 14 is an excellent choice for all around playing. |
| 14C4 | 17.09 | 0.673 | 26 | Offering the same rim contour and diameter as the 14A4a, with the standard "C" cup and backbore for a full, rich tone. |
| 15A4a | 17.14 | 0.675 | 27 | A larger diameter mouthpiece with a shallow "A" cup and tight "a" backbore for upper register playing. #4 semi-flat rim offers comfort in upper register. |
| 15A4 | 17.14 | 0.675 | 27 | Same as the 15A4a but with a larger "c" backbore for an open feel. |
| 15B | 17.12 | 0.674 | 26 | With the same diameter as the #15, this mouthpiece includes "B" style cup which produces a more brilliant sound than the standard #15 mouthpiece. |
| 15 | 17.12 | 0.674 | 26 | An excellent all-around mouthpiece which offers a free blowing, clear sound. |
| 15C4 | 17.14 | 0.675 | 26 | This mouthpiece is similar to the #15 but with the #4 semi-flat rim for increased endurance. |
| 16B4 | 17.2 | 0.677 | 26 | Same as the #16C4 except the shallower, medium-small "B" cup offers more resistance, providing a brighter quality of sound. The 16B4 is an excellent choice for Eb trumpet when a player requires a bigger rim diameter. |
| 16C4 | 17.2 | 0.677 | 26 | Similar to the 16 in dimensions, this mouthpiece offers our #4 semi-flat rim for a more traditional feel and increased endurance. |
| 16 | 17.2 | 0.677 | 26 | With all the standard Schilke charactistics, this medium-large diameter mouthpiece produces a full, free blowing quality. |
| 16C2 | 17.2 | 0.677 | 26 | This model offers the same options as the 16, but instead offers a #2 rim for increased flexibility. |
| 17B4 | 17.33 | 0.682 | 26 | Well suited for the player looking for a shallower cup in a larger diameter. Medium-small "B" cup offers more brilliance for projection with #4 semi-flat rim for comfort. |
| 17 | 17.33 | 0.682 | 26 | A compromise of all the medium characteristics, this mouthpiece is an excellent medium to large diameter mouthpiece. |
| 17D4 | 17.33 | 0.682 | 26 | This mouthpiece includes a deeper "D" cup and #4 semi-flat rim for improved endurance. |
| 17D4d | 17.33 | 0.682 | 26 | A larger blowing mouthpiece than the 17D4 because of the increase "d" backbore. |
| 18B4 | 17.52 | 0.69 | 26 | Ideal for a classical player looking for a commercial sound, the medium shallow cup and semi-flat rim provide resistance and comfort for upper register playing. Cup shape offers some sparkle in the sound with enough volume for tone. |
| 18 | 17.52 | 0.69 | 26 | The high point being nearer to the center makes this mouthpiece feel smaller than it is. The standard characteristics produce a rich, brilliant tone |
| 18C3d | 17.52 | 0.69 | 26 | Similar in dimension to the 18 but with a larger "d" backbore producing a large, teutonic tone. |
| 19 | 17.65 | 0.695 | 26 | The "C" cup, #3 rim and standard "c" backbore are similar to the #20 but with a slightly smaller diameter |
| 20 | 17.78 | 0.7 | 26 | This large diameter is for the robust embouchure. Original mouthpiece of choice for Renold O. Schilke. |
| 20D2d | 17.73 | 0.698 | 26 | Similar to the #20 in diameter but includes a larger "D" style cup, #2 semi-round rim and larger "d" backbore. |
| 22 | 18.03 | 0.71 | 26 | Similar to the #20 but with a larger inside dimeter. |
| 24 | 18.29 | 0.72 | 26 | Our largest cup diameter offered. This mouthpiece provides a huge volume of sound. |
Heavyweight Series Trumpet Mouthpieces
The Heavyweight Series is available in the following best-selling models. The additional mass provides a darker and subtly more focused sound, with more secure slotting and increased projection at louder dynamic levels.
| Model | mm | Inches | Throat | Description |
|---|---|---|---|---|
| 6A4a HVY | 15.99 | 0.63 | 27 | “Heavyweight” Profile. A shallow ‘A” cup with cushion #4 rim for extreme high register work. |
| 12A4a HVY | 16.71 | 0.658 | 27 | “Heavyweight” Profile. Similar to the 12B4 but with a shallow “A” cup, tight “a” backbore which adds both endurance and range. |
| 13A4a HVY | 16.76 | 0.66 | 27 | “Heavyweight” Profile. The shallow “A” cup, semi-flat #4 rim and tight “a” backbore creates an ideal lead mouthpiece. |
| 13 HVY | 16.89 | 0.665 | 26 | “Heavyweight” Profile. Ideal choice for a student or developing player with standard #3 rim contour. Rounder rim provides increased flexibility and quick response. “C” cup offers volume for tone. |
| 14A4a HVY | 17.09 | 0.673 | 27 | “Heavyweight” Profile. One of our most popular mouthpieces, the 14A4a offers a shallow “A” cup, semi-flat #4 rim and tight “a” backbore allows a player a strong upper register without sacrificing tonal production. |
| 14 HVY | 17.02 | 0.67 | 26 | “Heavyweight” Profile. With a standard rim, cup and backbore, the 14 is an excellent choice for all around playing. |
| 15A4a HVY | 17.14 | 0.675 | 27 | “Heavyweight” Profile. A larger diameter mouthpiece with a shallow “A” cup and tight “a” backbore for upper register playing. #4 semi-flat rim offers comfort in upper register. |
| 15 HVY | 17.12 | 0.674 | 26 | “Heavyweight” Profile. An excellent all-around mouthpiece which offers a free blowing, clear sound. |
| 16C4 HVY | 17.2 | 0.677 | 26 | “Heavyweight” Profile. Similar to the 16 in dimensions, this mouthpiece offers our #4 semi-flat rim for a more traditional feel and increased endurance. |
| 17 HVY | 17.33 | 0.682 | 26 | “Heavyweight” Profile. A compromise of all the medium characteristics, this mouthpiece is an excellent medium to large diameter mouthpiece. |
| 18 HVY | 17.52 | 0.69 | 26 | “Heavyweight” Profile. The high point being nearer to the center makes this mouthpiece feel smaller than it is. The standard characteristics produce a rich, brilliant tone. |
| 20 HVY | 17.78 | 0.7 | 26 | “Heavyweight” Profile. This large diameter is for the robust embouchure. Original mouthpiece of choice for Renold O. Schilke. |
Z Series Trumpet Mouthpieces
“Tighter and Brighter” – The Z Series trumpet mouthpieces feature a contour exterior profile which is lighter in mass for a quicker response. Also featured is our extra-tight ‘Z’ backbore which offers slightly more resistance than the standard ‘A’ backbore.
| Model | mm | Inches | Throat | Description |
|---|---|---|---|---|
| 6A4Z | 15.99 | 0.63 | 27 | CONTOUR PROFILE – A shallow ‘A” cup with cushion #4 rim for extreme high register work with tight ‘Z” backbore. |
| 13A4Z | 16.76 | 0.66 | 27 | CONTOUR PROFILE – The shallow “A” cup, semi-flat #4 rim and extra tight “Z” backbore creates an ideal lead mouthpiece with quick response and more resistance than standard model. |
| 14A4Z | 17.09 | 0.673 | 27 | CONTOUR PROFILE – Based our most popular 14A4A, offers a shallow “A” cup, semi-flat #4 rim and extra tight “Z” backbore. |
Symphony Series Trumpet Mouthpieces
An evolution in mouthpiece design utilizing several concepts from the standard Schilke line, the Symphony Series models are on the larger side of the mouthpiece spectrum creating a deep, vibrant sound with a well-focused center and conceptually developed to meet the demands of the modern orchestral player. They have comfortable rim shapes that provide a clean, crisp attack. They are offered with a standard cup depth or a deep bowl shape.
The 150 Series and “C” option for the Symphony Series (M1C, M150C, etc.) were developed working with Jack Sutte, trumpet player with the Cleveland Orchestra. The F cup models were originally developed for the Houston Ballet Orchestra trumpet section. The mouthpiece originally known as the “fluffy” has a flugel style cup and trumpet stem with the same rim contour and feel as the other models in this series. This has been a very popular custom choice for quieter passages where a cornet sound is desired without losing the control and focus of the sound.
| Model | Throat | Description |
|---|---|---|
| M1 | 24 | Standard bowl shape “C” cup with a 24 throat and Schmidt backbore. Excellent all around mouthpiece for both C and Bb trumpet. |
| M1C | 27 | Standard bowl shape “C” cup with tighter 27 throat and Schilke C backbore. A wonderful option for the player that desires a balanced, compact feel with more resistance than the M1 model. |
| M1D | 24 | Standard bowl cup with 24 throat and TIGHTER Schmidt backbore. Very good option for either Bb or Eb trumpet playing. |
| M1* | 24 | The “*” models share same rim and cup as the ‘M’ and “MD” models. They have a LARGER Schmidt backbore with a shorter throat that creates less resistance and a more open feel. |
| D1 | 24 | Deeper bowl shape cup that still provides feedback for control. The ‘D’ cups have a smaller version of the Schmidt backbore, tighter to balance the deeper cup. |
| F1 | 20 | The ‘F’ models offer a deep “V” shape cup that provides darker, warmer, more conical color allowing one to project at full capacity but maintain a soft mellow sound. These models utilize a shorter shank to compensate for cup volume plus a larger throat size & backbore taper. |
| Model | Throat | Description |
|---|---|---|
| M150 | 24 | Slightly smaller ‘150’ Rim diameter, standard bowl shape “C” cup, 24 throat and Schmidt backbore. |
| M150C | 27 | Slightly smaller ‘150’ Rim diameter, standard bowl shape “C” cup with tighter 27 throat and Schilke C backbore. |
| M150D | 24 | Slightly smaller ‘150’ Rim diameter, standard bowl shape “C” cup, 24 throat and TIGHTER Schmidt backbore. |
| M150* | 24 | LARGER Schmidt backbore with a shorter throat in a 150 rim diameter. More open feel. |
| D150 | 24 | Deeper bowl shape cup in ‘150’ rim diameter. |
| F150 | 20 | ‘F’ cup model with shorter shank in ‘150’ diameter. Offers a dark, mellow sound. |
| Model | Throat | Description |
|---|---|---|
| M2 | 24 | Slightly smaller ‘2’ Rim diameter, standard bowl shape “C” cup, 24 throat and Schmidt backbore. |
| M2C | 27 | Slightly smaller ‘2’ Rim diameter, standard bowl shape “C” cup with tighter 27 throat and Schilke C backbore. |
| M2D | 24 | Slightly smaller ‘2’ Rim diameter, standard bowl shape “C” cup, 24 throat and TIGHTER Schmidt backbore. |
| M2* | 24 | LARGER Schmidt backbore with a shorter throat in a 2 rim diameter. More open feel. |
| M2X | 24 | This model has the rim, throat, and backbore of a M2 but the cup shape of the M1 for slightly more cup volume. |
| D2 | 24 | Deeper bowl shape cup in ‘2’ rim diameter. |
| F2 | 20 | ‘F’ cup model with shorter shank in ‘2’ diameter. Offers a dark, mellow sound. |
| Model | Throat | Description |
|---|---|---|
| M3 | 24 | Slightly smaller ‘3’ Rim diameter, standard bowl shape “C” cup, 24 throat and Schmidt backbore. |
| M3C | 27 | Slightly smaller ‘3’ Rim diameter, standard bowl shape “C” cup with tighter 27 throat and Schilke C backbore. |
| M3D | 24 | Slightly smaller ‘3’ Rim diameter, standard bowl shape “C” cup, 24 throat and TIGHTER Schmidt backbore. |
| M3* | 24 | LARGER Schmidt backbore with a shorter throat in a 3 rim diameter. More open feel. |
| D3 | 24 | Deeper bowl shape cup in ‘3’ rim diameter. |
| F3 | 20 | ‘F’ cup model with shorter shank in ‘3’ diameter. Offers a dark, mellow sound. |
| Model | Throat | Description |
|---|---|---|
| M4C | 27 | The M4C ‘Symphony Series’ trumpet mouthpiece offers a comfortable rim profile and provides a full, vibrant sound! Created to meet the demands of an aspiring student or professional requiring a smaller inside rim diameter between M3C and M5C models. It futures a standard bowl shape “C” cup with tighter #27 throat and Schilke C backbore. |
| Model | Throat | Description |
|---|---|---|
| M5C | 27 | Slightly smaller ‘5’ Rim diameter, standard bowl shape “C” cup with tighter 27 throat and Schilke C backbore. |
S Series Trumpet Mouthpieces
Working on custom mouthpieces with American Jazz trumpeter Ryan Kisor, lead trumpet with the Lincoln Center Jazz Orchestra, we developed the S Series lead mouthpieces. Utilizing the rim shape of Symphony Series line with the Faddis cup, throat and backbore, we created a new line of high compression lead mouthpieces that provide a very comfortable, balanced mouthpiece with the resistance critical to playing in the extreme upper register with depth and resonance. Ideal for commercial lead trumpet playing.
| Model | Throat | Description |
|---|---|---|
| S5 | 28 | Rim Comparison = Schilke M5C or 13 |
| S4 | 28 | Rim Comparison = Schilke M4C or 14 |
| S3 | 28 | Rim Comparison = Schilke M3C or 15 |
P Series Trumpet Mouthpieces
Expanding options for piccolo trumpet, the P Series matches the Symphony Series rim shape with our shallow ‘A’ cup and Schilke ‘x’ backbore to provide a comfortable, responsive mouthpiece choice for piccolo trumpet that is balanced through the range of the piccolo with a clear, resonate sound. The P Series offer slightly less brilliance and more warmth than the traditional 11Ax and 14A4x piccolo trumpet mouthpieces. Available in three rim sizes in cornet shank or trumpet shank.
| Model | Throat | Description |
|---|---|---|
| P7 | 27 | Rim Comparison = Schilke 11 or 7C |
| P6 | 27 | Rim Comparison = Schilke 12 or 6C |
| P5 | 27 | Rim Comparison = Schilke 13 or 5C |
Signature Series Trumpet Mouthpieces
Jon Faddis XL Heavyweight Mouthpiece
In collaboration with Jazz Trumpet Legend Jon Faddis, this unique mouthpiece features a XL heavyweight blank profile which enhances projection and focus as well a rim profile, cup, and backbore preferred by Mr. Faddis.
| Model | Throat | Description |
|---|---|---|
| Faddis XL | 28 | An extra large “Heavyweight” trumpet mouthpiece, this model’s design is based on the mouthpiece used by legendary jazz artist, musician, conductor, composer and educator Jon Faddis for his S43HDL-F set-up. Faddis XL inner rim equivalent = Schilke 11 with an extra shallow cup. |
Marc Geujon ‘Soloiste’ Mouthpieces
Marc Geujon was instrumental in the design of the SB4-MG and SC4-MG Soloiste Series Bb & C Trumpets. Following the introduction of those models, Mr. Geujon was once again a driving force in design, this time on mouthpieces.
We are proud to introduce the new Soloiste Signature Series Trumpet Mouthpieces. A new rim contour, backbore design and exterior profile make these mouthpieces an exciting addition to the Schilke catalog.
| Model | mm | Inches | Throat | Description |
|---|---|---|---|---|
| MG1 Soloiste | 17.43 | 0.686 | 25 | A large sized trumpet mouthpiece, the MG1 Soloiste offers a unique tone that is full of warmth and color. Ideal for solo, chamber and orchestral literature, this mouthpiece is truly versatile. The MG1 Soloiste offers a fairly open feel due to the throat size and Geujon Signature backbore. This mouthpieces features a rim contour that was developed specifically for Mr. Geujon. Semi-round and with a high inside bite, this unique rim shape offers comfort and flexibility without feeling overly large for the player. |
| MG2 Soloiste | 17.43 | .686 | 26 | The same comfortable rim used on the MG1, the MG2 provides more efficiency due to a smaller throat size and slightly less cup volume. |
| Model | mm | Inches | Throat | Description |
|---|---|---|---|---|
| MG1R Soloiste | ||||
| MG2R Soloiste |
| Model | mm | Inches | Throat | Description |
|---|---|---|---|---|
| MG1P Soloiste | Available in cornet or trumpet shank. |
MOST Trumpet Mouthpieces
MOST Series trumpet mouthpieces were developed working with Schilke Artists Osamu Takahashi & Toshio Tanaka and are played by members of the renowned trumpet ensemble, The MOST. This series features a rim shape that was designed for Messrs. Takahashi & Tanaka, and falls between our #3 standard rim and #4 semi-flat rim in terms of contour and bite.
| Model | mm | Inches | Throat | Description |
|---|---|---|---|---|
| MOST 1 | 17.43 | 0.686 | 22 | The MOST 1 Signature Series Trumpet Mouthpiece offers a rich & pure tone with outstanding evenness throughout all ranges & dynamics. Designed with a standard cup depth and MOST-C Signature backbore. MOST Series trumpet mouthpieces feature a rim shape that was designed for Messrs. Takahashi and Tanaka, and falls between our #3 standard rim and #4 semi-flat rim in terms of contour and bite. |
| MOST 1M | 17.43 | 0.686 | 24 | Similar to MOST 1, with more efficient throat. With MOST-C Signature backbore. |
| MOST 1S | 17.43 | 0.686 | 23 | Similar to MOST 1, but with slightly deeper, more funnel-like cup shape. Offers a subtly darker and richer tone than the MOST 1. With MOST-C Signature backbore. |
| MOST 2 | 17.37 | 0.684 | 24 | Similar to MOST 1M, with slightly smaller inner cup diameter and slightly shallower cup. With MOST-C Signature backbore. |
| MOST 3 | 17.18 | 0.676 | 25 | With a smaller inner cup diameter than the MOST 1 or MOST 2, and a semi-shallow cup. With MOST-C Signature backbore. |
| MOST 4 | 16.94 | 0.666 | 25 | The smallest inner cup diameter of any MOST trumpet mouthpiece, with semi-shallow cup and MOST-B2 Signature backbore |
| Model | mm | Inches | Throat | Description |
|---|---|---|---|---|
| MOST 1-RT | 17.43 | 0.686 | 22 | The MOST 1 Signature Series Trumpet Mouthpiece offers a rich & pure tone with outstanding evenness throughout all ranges & dynamics. Designed with a standard cup depth and MOST-C Signature backbore. Designed for use with traditional rotary trumpets. |
| MOST 1S-RT | 17.43 | 0.686 | 23 | Similar to MOST 1, but with slightly deeper, more funnel-like cup shape. With MOST-C Signature backbore. Designed for use with traditional rotary trumpets. |
| MOST 2-RT | 17.33 | 0.682 | 24 | Similar to MOST 1, with slightly smaller inner cup diameter. With MOST-C Signature backbore. Designed for use with traditional rotary trumpets. |
| Model | mm | Inches | Throat | Description |
|---|---|---|---|---|
| MOST 5P | 17.13 | .674 | 22 | A medium sized piccolo trumpet mouthpiece with a wide & round rim contour. With MOST-X Signature backbore. |
