Model B5 Bb Trumpet

Slide background

Model X3 Bb Trumpet

Traditional B & X Series Designs by Renold Schilke:

Acclaimed for its exceptional intonation, ease in response, and outstanding projection, the Renold O. Schilke designed Bb trumpet has set the standard for playability and build quality since it was introduced in 1956.  The classic reverse main tuning slide with full radius bend, mouthpipe design and bore variation help create a responsive, open feel with an overall evenness throughout the range of the instrument at all dynamic levels.  This characteristic design is streamlined, clean and elegant.  The B and X models provide a balanced, comfortable playing experience with a superior tone quality.

  • B1 – ML Bore – (.460”/11.68mm) / L Bell – (5”/127.00mm) Yellow Brass Bell with #1 Taper
  • B3 – L Bore – (.463”/11.75mm) / M Bell – (5”/127.00mm) Yellow Brass Bell with #3 Taper
  • B5 – ML Bore – (.460”/11.68mm) / ML Bell – (5”/127.00mm) Copper Bell with #2 Taper
  • B6 – M Bore – (.450”/11.42mm) / ML Bell – (5”/127.00mm) Copper Bell with #2 Taper
  • B7 – M Bore – (.450”/11.42mm) / L Bell – (5”/127.00mm) Yellow Brass Bell with #1 Taper
  • X3 – L Bore – (.463”/11.75mm) / L Bell – (5”/127.00mm) Yellow Brass Bell with #1 Taper

Available Finishes:

  • Silver Plate
  • Gold Plate

^ Back to Top




Slide background

Model S22HD Bb Trumpet

Slide background

Model S22HD Bb Trumpet (Silver)

HD Series:

  • S22HD – L Bore – (.463”/11.75mm) / ML Bell – (4.875”/124mm) Yellow Brass with #2 Taper
  • S23HD – L Bore – ( .463”/11.75mm) / ML Bell – (4.875”/124mm) Yellow Brass with #3 Taper
  • S32HD – ML Bore – (.460”/11.68mm) / ML Bell – (4.875”/124mm) Yellow Brass with #2 Taper
  • S33HD – ML Bore – (.460”/11.68mm) / ML Bell – (4.875”/124mm) Yellow Brass with #3 Taper

The HD line of Bb trumpets offer a broad, rich tone with excellent intonation. Built in the high quality Schilke tradition, this new design compliments the lighter B and X series trumpets.  Designed for the symphonic player, the ML and L bore HD trumpets will feel controlled and powerful yet have the ability to project even the softest passages.

Available Finishes:

  • Silver Plate
  • Gold Plate
  • Lacquer

^ Back to Top




Slide background

Model HC1-L Trumpet

Slide background

Model HC2 - L Trumpet

Handcraft Series

  • HC1 – XL Bore – (.468”/11.88mm) / XL Bell – (4.750”/120mm) / Yellow Brass Bell with #0 Taper
  • HC2 – XL Bore – (.468”/11.88mm) / XL Bell – (4.750”/120mm) / Copper Bell with #0 Taper

The new Schilke Handcraft offers a truly unique sound.  With its extra-large bore and bell design, the Handcraft creates a dark, smokey tone that will project in any performance venue.  Using some of the early design influences from Renold Schilke’s years prior to the development of the Schilke company, this trumpet reintroduces a rich smooth sound that has been unavailable for many years.

Available Finishes:

  • Silver Plate
  • Gold Plate
  • Lacquer

^ Back to Top




S42LF – Faddis Model*

  • M Bore – (.450”/11.42mm)
  • ML Bell – (5”/127.00mm) Yellow Brass Tuning Bell with #2 Taper

Built to the specifications of the legendary jazz artist, musician, conductor, composer and educator Jon Faddis, this tuning bell instrument includes a custom round tuning slide without waterkeys, adjustable tuning bell soundpost, heavy valve caps and removed “nibs” on the 2nd slide.

Available Finishes:

  • Silver Plate
  • Gold Plate

* Note: Adjustable tuning slide brace included with S42LF Faddis Model

OPTIONAL FIXED BELL S42

  • M Bore – (.450”/11.42mm)
  • ML Bell – (5”/127.00mm)
  • Yellow Brass bell with #2 Taper

(The traditional Schilke fixed bell S42 is also available as a standard model.)

^ Back to Top




Slide background

Model i32 Trumpet

Schilke i32 Bb Trumpet

A top innovative leader in brass manufacturing in the world for nearly 60 years, Schilke is proud to present a new semi-professional trumpet, the Model i32 Bb Trumpet. The i32 features include the classic Schilke reverse leadpipe design, a .460″ medium-large bore with new #2i taper Yellow Brass Bell in silver plate finish. Versatile and responsive the i32 is flexible enough to work in any style or genre and is ideal for an advanced student. Old world craftsmanship and 21st century technology combine to create an instrument with professional features and playing characteristics at a more economical price point. It is hand built entirely by Schilke craftsmen located in Melrose Park, IL, USA.

  • ML Bore – (.460”/11.68mm)
  • ML Bell – (4.875”/124.00mm) Yellow Brass Bell with #2i Taper

i32-CaseThe i32 outfit is supplied with a case and mouthpiece. The case featured with the i32 is a stylish gray, lightweight single trumpet case with shoulder strap, which allows for a secure and protective vertical fit. The case is branded with an embroidered logo, SCHILKE CHICAGO USA. The mouthpiece supplied is a Schilke 16C4. Available in silver plate finish only.

^ Back to Top


S42L-Faddis-Model

Tuning Bell Bb, C, Eb/D, and G/F Trumpets

The detachable tuning bell design is available on all Schilke Bb, C, Eb/D, and G/F custom-built trumpets.  By tuning from the bell, the instrument offers an improved feel and superior intonation. In general, the playing characteristic of this instrument will be more open or “free” feeling mainly in the upper register.  Because the tuning bell design offers less bell bracing, the general response of the instrument feels quicker.  By removing the standard “S” brace on the front section of the bell, the instrument resonates or “rings” which improves projection.  With the lack of fixed bracing, the tuning bell design is fragile and caution should be used when carrying a tuning bell trumpet in a soft sided case.

“Beryllium”:  “Beryllium” bells are made up of extremely lightweight copper which offers more direct, compact projection.  Optional on Schilke Bb, C, Eb/D trumpets.

Sterling Silver:   Sterling silver bells are slightly thicker than our traditional bells and offer a wider range of overtones which creates a dark, rich tone.  Optional on Schilke Bb, C, Eb/D trumpets.

Bell Sizes:

  • #0 – Extra large throat with 4.750” bell rim
  • #1 – Large throat with 5” bell rim
  • #2 – Medium large throat with 5” bell rim
  • #3 – Larger throat than #2 but with a faster taper to the valve section.  Overall less volume than the #2
  • #4 – Medium small throat for Eb/D instruments
  • #5 – Medium small throat for G/F instruments
  • #8 – Narrow throat for piccolo and G trumpets

^ Back to Top
